CW613N Forging Brass

CW613N Forging Brass Specification

Processing Type
Extruded & Drawn

Finish
Extruded & Drawn

Surface Finishing
Bright

Color
Golden

Dimension (L*W*H)
16 Foot (ft)

Tolerance
1.5 to 125 Millimeter (mm)

Usage
Automotive, Builders Hardware, Consumer Fasteners, Industrial Plumbing

Application
Automotive, Builders Hardware, Consumer Fasteners, Industrial Plumbing

Material
Brass

Size
1.5mm to 125mm

Product Type
Architecture, Builders Hardware

Grade
CW613N

Alloy
Yes

Temper
1/2 Hard

Length
16 Foot (ft)

Shape
Round

Diameter
1.5 Millimeter (mm)

Warranty
NA

CW613N Forging Brass Trade Information

Minimum Order Quantity
2000 Kilograms

Delivery Time
4 Week

About CW613N Forging Brass

CW613, brass, is a readily extrudable leaded alpha/beta brass with a small Tin addition, which gives little bit of strength and resistance to corrosion. The lead gives free cutting properties. CW613 is available as extruded rods and flats which are typically used in builders hardware.

Chemical Composition

Elements	Min (%)	Max (%)
Cu	59.00	60.00
Pb	1.60	2.50
Sn	0.20	0.50
Fe	- -	0.40
Al	-	0.10
Ni	-	0.30
Total Others	-	0.20
Zn	Remainder

Mechanical Properties According To EN12165 (As Per Temper H070)

Range (mm)	From	To	UTS Min	PS Min	Elongation Min (%)	Hardness Min (HV)	Hardness Max (HV)
Round (Dia)	1.5	75	-	-	-	70	170
Hex (A/F)	3	70	-	-	-	70	170
Square (A/F)	3	60	-	-	-	70	170
Rectangle (Thickness)	3	50	-	-	-	70	170

Physical Properties

Physical Properties	Metric	English
Density	8.40 g/cc	0.303 lb/in3
CTE, linear	26.0 m/m-C	14.4 in/in-F
Specific Heat Capacity	0.380 J/g-C	0.0908 BTU/lb-F
Thermal Conductivity	113 W/m-K	784 BTU-in/hr-ft-F
Melting Point	880-900 C	1620 1650 F
Solidus	880 C	1620 F
Liquidus	900 C	1650F
