CW619N Forging Brass

CW619N Forging Brass Specification

Application
Automotive, Builders Hardware, Consumer Fasteners, Industrial Plumbing

Finish
Extruded & Drawn

Dimension (L*W*H)
16 Foot (ft)

Tolerance
1.5 to 125 Millimeter (mm)

Surface Finishing
Bright

Processing Type
Extruded & Drawn

Product Type
Architecture, Builders Hardware

Material
Brass

Size
1.5mm to 125mm

Usage
Automotive, Builders Hardware, Consumer Fasteners, Industrial Plumbing

Color
Golden

Grade
CW619N

Alloy
Yes

Temper
1/2 Hard

Length
16 Foot (ft)

Shape
Round

Diameter
1.5 Millimeter (mm)

Warranty
NA

CW619N Forging Brass Trade Information

Minimum Order Quantity
2000 Kilograms

Delivery Time
4 Week

About CW619N Forging Brass

CW619, brass, is a readily extrudable leaded alpha/beta brass with a small Tin addition, which gives little bit of strength and resistance to corrosion. The lead gives free cutting properties. CW619 is available as extruded rods and flats which are typically used in builders hardware.

Chemical Composition

Elements	Min (%)	Max (%)
Cu	57.00	59.00
Pb	1.60	2.50
Sn	0.20	0.50
Fe	- -	0.40
Al	-	0.10
Ni	-	0.30
Total Others	-	0.20
Zn	Remainder

Mechanical Properties According To EN12167 (As Per Temper H110)

Range (mm)	From	To	UTS Min	PS Min	Elongation Min (%)	Hardness Min (HB)	Hardness Max
Round (Dia)	6	60	-	-	-	110	-
Hex (A/F)	6	60	-	-	-	110	-
Square (A/F)	6	60	-	-	-	110	-
Rectangle (Thickness)	6	60	-	-	-	110	-

Physical Properties

Physical Properties	Metric	English
Density	8.40 g/cc	0.303 lb/in3
CTE, linear	26.0 m/m-C	14.4 in/in-F
Specific Heat Capacity	0.380 J/g-C	0.0908 BTU/lb-F
Thermal Conductivity	113 W/m-K	784 BTU-in/hr-ft-F
Melting Point	880-900 C	1620 1650 F
Solidus	880 C	1620 F
Liquidus	900 C	1650F
