CW510L Lead Free Brass

CW510L Lead Free Brass Specification

Strength
Tensile Strength 280-550 MPa

Hardness
65-180 HV

Purity
99% min.

Material
Lead Free Brass

Alloy
CW510L

Shape
Other

Moisture
Nil

Chemical Composition
Cu 61-63%, Zn remainder, Pb < 0.09%

Application
Fittings, Sanitary, Drinking Water Systems, Valves, Automotive

Dimension (L*W*H)
Customizable

Color
Golden Yellow

Surface Finish
Bright / Polished / Matt

Electrical Conductivity
22% IACS

Melting Point
900-940C

Machinability
Good

Density
8.43 g/cm3

Thermal Conductivity
110 W/mK

Corrosion Resistance
Excellent

Elongation
10-38%

Standard
EN 12165, EN 12164, EN 12167

CW510L Lead Free Brass Trade Information

Minimum Order Quantity
2 Tons

Supply Ability
1000 Tons Per Month

Delivery Time
7 Days

About CW510L Lead Free Brass

CW510L

CW510L is a lead-free material which is however quite suitable for machining Due to its structural constitution. CW510 can be therefore used as a cost-effective Replacement for conventional lead-containing machining brass provided that it must not meet high requirements as regards mechanical properties and corrosion Resistance.

Superior Environmental Performance

CW510L Lead Free Brass stands out for its minimal lead content, aligning with global regulations for safe drinking water applications. Its composition ensures both high purity and safety, making it suitable for sensitive uses such as sanitary fixtures and valves. The alloy is an excellent choice for industries prioritizing sustainability and environmental compliance.

Versatile Mechanical and Physical Properties

This alloy offers a balance of strength (tensile: 280-550 MPa), hardness (65-180 HV), and ductility (elongation: 10-38%). Its good machinability and outstanding corrosion resistance make it adaptable for demanding applications in automotive, plumbing, and fluid handling industries. The golden yellow color enhances both functional and aesthetic appeal.

FAQ's of CW510L Lead Free Brass:

Q: How is CW510L Lead Free Brass typically used in various industries?

A: CW510L Lead Free Brass is widely utilized in the production of fittings, sanitary ware, drinking water systems, valves, and automotive components. Its lead-free composition and excellent corrosion resistance make it ideal for applications requiring safety and durability, especially in environments involving potable water.

Q: What distinguishes CW510L from other brass alloys?

A: Unlike traditional brass alloys, CW510L contains less than 0.09% lead, delivering high purity (minimum 99%) and compliance with EN 12165, EN 12164, and EN 12167 standards. Its low lead content ensures suitability for sensitive applications, particularly where contact with drinking water is required.

Q: Where can CW510L Lead Free Brass be sourced in India?

A: CW510L Lead Free Brass is manufactured and supplied by reputable brass manufacturers across India. It is available in multiple forms-including bars, rods, sheets, and strips-with customizable dimensions and various surface finishes tailored to customer requirements.

Q: What is the manufacturing process for CW510L Lead Free Brass?

A: CW510L is produced by alloying copper (61-63%) with zinc and maintaining lead levels below 0.09%. The material is shaped through extrusion, rolling, or casting into bars, rods, sheets, or strips, followed by surface finishing to achieve bright, polished, or matt appearances.

Q: What benefits does CW510L offer for drinking water systems?

A: The lead-free nature of CW510L significantly reduces the risk of lead contamination, ensuring potable water safety. Its excellent corrosion resistance and high mechanical performance further contribute to longer service life in water handling and sanitary installations.

Q: When should engineers choose CW510L over other brass alloys?

A: Engineers should select CW510L when applications demand compliance with lead-reduction directives, exceptional corrosion resistance, and reliable mechanical properties-particularly in fittings, valves, or parts coming into direct contact with drinking or sanitary water.
